Teknik çizim

product

BELOW GROUND GRP OIL WATER SEPARATOR MANUAL V CLASS II

Yerli Üretim

Stok Kodu: 4322

The EN 858 class II compliant manual oil-water separator is made of glass fiber
reinforced plastic (GRP) material and has an integrated
sludge trap. It is designed to be mounted underground below the frost line. Its round shape and non-porous
surface provide resistance to oils and acids on the inner and outer surfaces, thus guaranteeing easy and precise cleaning and disposal. Inlet and outlet connections are suitable push sockets or
pipe connections. The separator includes a ductile iron access hatch with a leak-proof rubber seal, compliant with EN 124 D400 load class (40
tons). Optionally, it can be equipped with an oil level monitoring alarm
device and a sampling shaft.
Fuel stations, Parking lots, Truck loading and unloading areas, Car dealerships, repair shops,
Car washes, Bus garages, Military hangars and storage facilities, Fire stations, Engine cleaning workshops,
Vehicle recovery parking areas,
Airport apron, Train - Metro stations, Container terminals, Industrial facilities, oil facilities with a risk of accidental oil spills.
Documents:

CodeNS(lt/sec)DNTotal
Volume
(lt)		Oil Volume
(lt)		Sludge
Volume
(lt)		AA1CC1C2H1H2ELİNK
442233100887250320100014001500-25001400108012001130690

SHOW


4422661501554500630100014002400-34002300108020501980690SHOW
4422101015026908501050120016002800-38002700108024502380690SHOW
44221515200376412601620120016003700-47003700108034003330690SHOW
44222020250517517002150150019003200-42003400108030002930690SHOW
44222525250641021002690150019004000-50004100108037003630690SHOW
44223030300763025003100200024002700-37003000108025002430690SHOW
442240403001045034004100200024003600-46003900108034003330690SHOW
442250503001270042505100235027503100-41003500108036003530690SHOW
442260603001530050306100235027503700-47004100108036003530690SHOW
442280804002070067508100300034003100-41003600108030002930690SHOW
442210010040024940830010100300034004300-53004200108036003530690SHOW
